| Cảm biến hình | Xấp xỉ 1/2.8 type CMOS image sensor |
| Cường độ ánh sáng nhỏ nhất | Color : 0.006 lx (30IRE, F1.2, 1/30s) *1 Color : 0.008 lx (50IRE, F1.2, 1/30s) BW : 0.004 lx (50IRE, F1.2, 1/30s) |
| Cân bằng trắng | ATW1/ ATW2/ AWC |
| Tốc độ màn trập | [60fps mode] 1/60 Fix to 1/10000 Fix, [30fps/15fps*2 mode] 1/30 Fix to 1/10000 Fix [50fps mode] 1/50 Fix to 1/10000 Fix, [25fps/12.5fps*2 mode] 1/25 Fix to 1/10000 Fix |
| i-PRO Intelligent Auto | On / Off |
| i-PRO Super Dynamic*3 | On / Off, The level can be set in the range of 0 to 31. |
| Dải tần nhạy sáng | Max.144 dB (Super Dynamic : On) |
| Bù sáng | BLC (Back light compensation) / HLC (High light compensation) / Off (only when Super dynamic / Intelligent Auto : Off) |
| Bù sương mù | On / Off (only when Intelligent auto / auto contrast adjust : Off) |
| AGC | The level can be set in the range of 0 to 11. |
| Color/BW (ICR) | Off / On / Auto1 (Normal) / Auto2 (IR Light) / Auto3 (SCC) |
| Giảm nhiễu tự động (DNR) | The level can be set in the range of 0 to 255. |
| Phát hiện chuyển động (VMD) | On / Off, 4 areas available |
| Phát hiện chuyển cảnh | On / Off, 1 areas available |
| Phát hiện âm thanh | On / Off |
| Phân loại âm thanh | Gunshot, Yell, Vehicle horn, Glass break |
| Phân tích AI | Có |
| Vùng bảo mật | On / Off, Up to 8 zones available |
| VIQS | On / Off, Up to 8 zones available |
| Image rotation*4 | 0 ° / 90 ° / 180 °(Upside-down) / 270 ° |
| OSD | On / Off, Up to 40 characters (alphanumeric characters, marks) |
| Điều chỉnh tiêu điểm | Auto back focus / Manual / Adjusting method (Auto / Preset / Fix) |
| Kiểm soát hình ảnh | Brightness, AUX On / Off |
| Âm thanh | Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High Audio Output : On / Off Volume adjustment : Low / Middle / High |
| GUI / Cài đặt ngôn ngữ | English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Network IF | 10Base-T / 100Base-TX, RJ45 connector |
| H.265/ H.264/ JPEG (MJPEG) | [16:9 mode (60 fps mode)]*3 , [16:9 mode (30 fps mode)], [16:9 mode (50 fps mode)]*3 , [16:9 mode (25 fps mode)] 1920×1080, 1280×720, 640×360, 320×180 [4:3 mode (30 fps mode)]*2 , [4:3 mode (25 fps mode)]*2 1280×960, VGA, QVGA [16:9 mode (60 fps mode)]*3 , [16:9 mode (30 fps mode)], [16:9 mode (50 fps mode)]*3 , [16:9 mode (25 fps mode)] 1920×1080, 1280×720, 640×360, 320×180 [4:3 mode (30 fps mode)]*2 , [4:3 mode (25 fps mode)]*2 1280×960, VGA, QVGA [4:3 mode (15 fps mode)]*2 , [4:3 mode (12.5 fps mode)]*2 2048×1536*3, 1280×960, VGA, QVGA |
| JPEG – Chất lượng hình ảnh | 10 steps |
| Mã hóa thông minh i-PRO | GOP (Group of pictures control): Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/ Advanced(Fixed GOP 60s w/1s key-frame)/ Frame rate control (Variable GOP 4s-16s with frame rate control) *Advanced and Frame rate control are only available with H.265. Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off |
| Nén âm thành | G.726 (ADPCM) : 16 kbps / 32 kbps G.711 : 64 kbps AAC-LC*6 : 64 kbps / 96 kbps / 128 kbps |
| Truyền âm thanh | Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Hỗ trợ giao thức | IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X,DiffServ, LLDP, SFTP, MQTT IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, LLDP, SFTP, MQTT |
| Số người dùng tối đa | Up to 14 users (Depends on network conditions) |
| Thẻ nhớ SDXC/SDHC/SD | H.265 / H.264 recording : Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure JPEG recording : Manual REC / Alarm REC (Pre/Post) / Backup upon network failure Available SDXC/SDHC/SD Memory Card microSDXC memory card: 64 GB, 128 GB, 256 GB, 512 GB microSDHC memory card: 4 GB, 8 GB, 16 GB, 32 GB microSD memory card: 2 GB |
| Tương thích thiết bị di dộng | iPad, iPhone, Android™ terminals |
| Nguồn báo động | 3 terminals input, VMD alarm, Command alarm, Audio detection alarm |
| Báo động | SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification Indication on browser, Panasonic alarm protocol output |
| Đầu ra (for Adjustment) | VBS : 1.0 V [p-p] / 75 Ω, composite, Pin jack An NTSC or PAL signal can be outputted from camera |
| Đầu vào âm thanh | ø3.5 mm stereo mini jack |
| Đầu ra âm thanh | ø3.5 mm stereo mini jack (monaural output) Output impedance : Xấp xỉ 600 Ω (unbalanced) Output level : –20 dBV |
| External I/O Terminals | ALARM IN 1 (Black & white input, Auto time adjustment input) (x1), ALARM IN 2 (ALARM OUT) (x1), ALARM IN 3 (AUX OUT) (x1) |
| Độ an toàn | UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1 |
| EMC | FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassB, EN55035 |
| Nguồn điện và mức tiêu thụ | DC power supply : DC12 V 480 mA, Xấp xỉ 5.8 W PoE (IEEE802.3af compliant) Device : DC48 V 130 mA, Xấp xỉ 6.3 W (Class 2 device) |
| Nhiệt độ hoạt động | -10 °C to +50 °C (14 °F to 122 °F) |
| Độ ẩm hoạt động | 10 to 90 % (Không ngưng tụ) |
| Kích thước | 75 mm (W) x 57 mm (H) x 146 mm (D) {2-15/16 inches (W) x 2-1/4 inches (H) x 5-3/4 inches (D)} (excluding lens / power cord plug) |
| Trọng lượng | 370 g { 0.82 ibs.} |
