| Cảm biến hình | Xấp xỉ 1/2.8 type CMOS image sensor |
| Cường độ ánh sáng nhỏ nhất | Color : 0.0011 lx (30IRE, F1.7, 1/30s) *1 Color : 0.0015 lx (50IRE, F1.7, 1/30s) BW : 0.008 lx (50IRE, F1.7, 1/30s) BW : 0 lx (50IRE, F1.7,1/30s with IR LED) |
| Cân bằng trắng | ATW1 / ATW2 / AWC |
| Tốc độ màn trập | [60 fps Mode] 1/60 Fix to 1/10000 Fix, [30 fps/15 fps mode] 1/30 Fix to 1/10000 Fix [50 fps Mode] 1/50 Fix to 1/10000 Fix, [25 fps/12.5 fps mode] 1/25 Fix to 1/10000 Fix |
| Tự động | On / Off |
| Super Dynamic*2 | On / Off, The level can be set in the range of 0 to 31. |
| Dải tần nhạy sáng | Max.144 dB (Super Dynamic : On, Level 31) |
| Bù sáng | BLC (Back light compensation) / HLC (High light compensation) / Off (only when Super dynamic / Intelligent Auto : Off) |
| Bù sương mù | On / Off (only when Intelligent auto / auto contrast adjust : Off) |
| AGC | The level can be set in the range of 0 to 11. |
| Color/BW (ICR) | Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC) |
| Đèn hồng ngoại | High / Middle / Low / Off, Maximum irradiation distance : 70 m {Xấp xỉ 230 ft} (30IRE) *1 50 m {Xấp xỉ 164 ft} (50IRE) |
| Giảm nhiễu tự động (DNR) | The level can be set in the range of 0 to 255. |
| Phát hiện chuyển động (VMD) | On / Off, 4 areas available |
| Phát hiện thay đổi cảnh (SCD) | On / Off, 1 areas available |
| Phát hiện âm thanh | On / Off |
| Phân loại âm thanh | Gunshot, Yell, Vehicle horn, Glass break |
| Phân tích AI | Có |
| Vùng bảo mật | On / Off, Up to 8 zones available |
| VIQS | On / Off, Up to 8 zones available |
| Image rotation*3 | 0 ° / 90 ° / 180 ° / 270 ° |
| OSD | On / Off, Up to 40 characters (alphanumeric characters, marks) |
| Điều chỉnh tiêu điểm | Auto focus |
| Zoom quang học | 2.3x (Motorized zoom / Motorized Focus) |
| Tùy chọn zoom | 2.3x – 6.9x (when resolution is 640 x 360) |
| Tiêu cự (f) | 9 – 21 mm {11/32 inches – 13/16 inches} |
| Góc quan sát | [16 : 9 mode] Horizontal : 15° (TELE) – 36° (WIDE), Vertical : 9° (TELE) – 20° (WIDE) [ 4 : 3 mode] Horizontal : 11° (TELE) – 27° (WIDE), Vertical : 9° (TELE) – 20° (WIDE) |
| Tỷ lệ khẩu độ | 1 : 1.7 (WIDE) – 1 : 3.0 (TELE) |
| Phạm vi lấy nét | 2 m {78-3/4 inches} – ∞ |
| Phát hiện (25ppm / 8ppf) | Wide: 118.2 m / 387.7 ft, Tele: 291.7 m / 956.9 ft |
| Quan sát (62.5ppm / 19ppf) | Wide: 47.3m / 155.1 ft, Tele: 116.7 m / 382.8 ft |
| Nhận biết (125ppm / 38ppf) | Wide: 23.6 m / 77.5 ft, Tele: 58.3 m / 191.4 ft |
| Xác định (250ppm / 76ppf) | Wide: 11.8 m / 38.8 ft, Tele: 29.2 m / 95.7 ft |
| Gắn trần | Horizontal : ±180 ° (PAN rotation part) Vertical : 0 ° to 100 ° (TILT rotation part) Yaw : –190 ° to +100 ° (YAW rotation part) |
| Gắn tường | Horizontal : ±100 ° (TILT rotation part)* Vertical : ±100 ° (TILT rotation part)* Yaw : –190 ° to +100 ° (YAW rotation part) * You can change between horizontal and vertical angels by adjusting the PAN rotation part. |
| Kiểm soát hình ảnh | Brightness, AUX On / Off |
| Âm thanh | Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High Audio Output : On / Off Volume adjustment : Low / Middle / High |
| GUI / Setup Menu Language | English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Browser*4 | Microsoft Edge, Firefox, Google Chrome |
| Network IF | 10Base-T / 100Base-TX, RJ45 connector |
| H.265/ H.264/ JPEG (MJPEG) | [16 : 9 mode (60 fps mode)]*2 , [16 : 9 mode (30 fps mode)], [16 : 9 mode (50 fps mode)]*2 , [16 : 9 mode (25 fps mode)] 1920×1080, 1280×720, 640×360, 320×180 [4 : 3 mode (30 fps mode)], [4 : 3 mode (25 fps mode)] 1280×960, VGA, QVGA [4 : 3 mode (15 fps mode)], [4 : 3 mode (12.5 fps mode)] 2048×1536*5 , 1280×960, VGA, QVGA |
| JPEG – Chất lượng hình ảnh | 10 steps |
| Mã hóa thông minh | GOP (Group of pictures control): Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/ Advanced(Fixed GOP 60s w/1s key-frame)/ Frame rate control (Variable GOP 4s-16s with frame rate control) *Advanced and Frame rate control are only available with H.265. Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off |
| Nén âm thanh | G.726 (ADPCM) : 16 kbps / 32 kbps G.711 : 64 kbps AAC-LC*7 : 64 kbps / 96 kbps / 128 kbps |
| Truyền âm thanh | Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Giao thức hỗ trợ | IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X,DiffServ, LLDP. SFTP, MQTT IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, LLDP. SFTP, MQTT |
| Số lượng người dùng tối đa | Up to 14 users (Depends on network conditions) |
| Thẻ nhớ SDXC/SDHC/SD | H.265 / H.264 recording : Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure JPEG recording : Manual REC / Alarm REC (Pre/Post) / Backup upon network failure Available SDXC/SDHC/SD Memory Card : microSDXC memory card : 64 GB, 128 GB, 256 GB, 512 GB microSDHC memory card : 4 GB, 8 GB, 16 GB, 32 GB microSD memory card : 2 GB |
| Tương thích thiết bị di động | iPad, iPhone, Android™ terminals |
| ONVIF Profile | G / M / S / T |
| Nguồn báo động | 3 terminals input, VMD alarm, Command alarm, Audio detection alarm |
| Báo động | SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification Indication on browser, Panasonic alarm protocol output |
| Monitor Output (for Adjustment) | VBS : 1.0 V [p-p] / 75 Ω, composite, Pin jack An NTSC or PAL signal can be outputted from camera |
| Audio input*8 | ø3.5 mm stereo mini jack |
| Audio Output*8 | ø3.5 mm stereo mini jack (monaural output) Output impedance : Xấp xỉ 600 Ω (unbalanced) Output level : –20 dBV |
| External I/O Terminals*8 | ALARM IN 1 (Alarm input 1/ Black & white input/ Auto time adjustment input) (x1) ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1) ALARM IN 3 (Alarm input 3/ AUX OUT) (x1) |
