| Cảm biến hình | 1/2.8 type CMOS image sensor |
| Cường độ ánh sáng nhỏ nhất | Color : 0.07 lx, BW : 0.04 lx (50IRE, F1.3, Maximum shutter : Off (1/30s), AGC : 11) BW : 0 lx (50IRE, F1.3, Maximum shutter : Off (1/30 s), AGC : 11, when the IR LED is lit) Color : 0.0044 lx, BW : 0.003 lx (50IRE, F1.3, Maximum shutter : max. 16/30s, AGC : 11) |
| Cân bằng trắng | ATW1/ATW2/AWC |
| Tốc độ màn trập | [30fps mode] 1/30 Fix to 1/10000 Fix [25fps mode] 1/25 Fix to 1/10000 Fix |
| AI Intelligent Auto | On / Off |
| Dải động | On / Off, The level can be set in the range of 0 to 31. |
| Dải tần nhạy sáng | Max.132 dB (Super Dynamic : On, Level : 30 or more, 15fps) |
| Bù sáng | BLC (Back light compensation) / HLC (High light compensation) / Off The level can be set in the range of 0 to 31. (only when Super dynamic / AI Intelligent Auto : Off) |
| Bù sương | On / Off, The level can be set in the range of 0 to 8 (only when AI Intelligent auto / auto contrast adjust : Off) |
| AGC | The level can be set in the range of 0 to 11. |
| Color/BW (ICR) | Off / On (IR Light Off) / On (IR Light On) / Auto1(IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC) |
| Đèn LED | High / Middle / Low / Off, Maximum irradiation distance : 40 m {Xấp xỉ 131 ft} |
| Giảm nhiễu động | The level can be set in the range of 0 to 255. |
| Phát hiện chuyển động (VMD) | On / Off, 4 areas available |
| SCD (Phát hiện chuyển cảnh) | On / Off, 1 area available |
| Vùng bảo mật | On / Off, Up to 8 zones available |
| Xoay hình | 0 ° (Off) / 90 ° / 180 ° (Upside-down) / 270 ° |
| OSD | On / Off, Up to 20 characters (alphanumeric characters, marks) |
| Tùy chọn thu phóng | 3.1x (Motorized zoom / Motorized focus) |
| Tùy chọn zoom | 3.1x – 9.3x (when resolution is 640×360) |
| Zoom tự động | Choose from 3 levels of x1, x2, x4 |
| Độ dài tiêu cự | 2.9 mm – 9 mm {1/8 inches – 11/32 inches} |
| Tỷ lệ khẩu độ | 1 : 1.3 (WIDE) – 1 : 2.5(TELE) |
| Phạm vi tiêu điểm | 0.3 m {11-13/16 inches} – ∞ |
| Góc nhìn | [16 : 9 mode ] Horizontal : 34° (TELE) – 106° (WIDE), Vertical : 19° (TELE) – 57° (WIDE) *[4:3 mode] is not supported. |
| Phát hiện | (25ppm / 8ft) Wide: 200.96 m / 659.32 ft, Tele: 46.3 m / 151.90 ft |
| Quan sát | (62.5ppm / 19ft) Wide: 80.38 m / 263.72 ft, Tele: 18.52 m / 60.76 ft |
| Nhận biết | (125ppm / 38ft) Wide: 40.19 m / 131.86 ft, Tele: 9.26 m / 30.38 ft |
| Xác định | (250ppm / 76ft) Wide: 20.1 m / 65.93 ft, Tele: 4.63 m / 15.19 ft |
| Tùy chọn góc | Horizontal : ±180 ° (Adjust by horizontal (PAN) angle) Vertical : 0 ° to 100 ° (Adjust by vertical (TILT) angle) Yaw : –190 ° to +100 ° (Adjust by azimuth (YAW) angle) |
| Tùy chọn góc (Gắn tường) | Horizontal : ±100 ° (Adjust by vertical (TILT) angle)* Vertical : ±100 ° (Adjust by vertical (TILT) angle)* Yaw : –190 ° to +100 ° (Adjust by azimuth (YAW) angle) *You can change between horizontal and vertical angels by adjusting the horizontal (PAN) angle |
| Kiểm soát hình ảnh | Brightness, AUX On / Off |
| Âm thanh | Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High Audio Output : On / Off Volume adjustment : Low / Middle / High |
| GUI / Cài đặt ngôn ngữ | English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Network IF | 10Base-T / 100Base-TX, RJ45 connector |
| Độ phân giải H.265/ H.264 JPEG (MJPEG) | [16 : 9 mode ] 3072×1728*7, 2560×1440, 1920×1080, 1280×720, 640×360, 320×180 *[4:3 mode] is not supported. |
| H.265/H.264 | [Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort [Transmission Type] Unicast port (AUTO)/ Unicast port (MANUAL)/ Multicast |
| JPEG | [Image Quality] 10 steps |
| Mã hóa thông minh | Smart Facial Coding : On (Smart Facial Coding*) / On (Auto VIQS) / Off *Smart Facial Coding is only available with Stream(1). GOP (Group of pictures) control :On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off *On (Frame rate control) and On (Advanced) are only available with H.265. |
| Nén âm thanh | G.726 (ADPCM) : 16 kbps / 32 kbps , G.711 : 64 kbps AAC-LC : 64 kbps / 96 kbps / 128 kbps |
| Truyền âm thanh | Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Giao thức hỗ trợ | IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, FTP, SMTP, DNS, NTP, SNMP, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ |
| Số người truy cập tối đa | Up to 14 users (Depends on network conditions) |
| Thẻ nhớ SDXC/SDHC/SD | H.265 / H.264 recording : Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure JPEG recording : Manual REC / Alarm REC (Pre/Post) / Backup upon network failure Compatible SDXC/SDHC/SD Memory Card : Panasonic 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64 GB**, 128 GB**, 256 GB** model *SDHC card, ** SDXC card (except miniSD card and microSD card) |
| Thiết bị di động tương thích | iPad, iPhone, AndroidTM terminals |
| ONVIF Profile | G / S / M / T |
| Nguồn cảnh báo | 3 terminals input, VMD alarm, Command alarm |
| Cảnh báo | SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification, Indication on browser, FTP image transfer, Panasonic alarm protocol output |
| Đầu ra hình | VBS : 1.0 V [p-p] / 75 Ω, composite, Pin jack An NTSC or PAL signal can be outputted from camera |
| Đầu vào âm thanh | ø3.5 mm stereo mini jack [For microphone input] Recommended applicable microphone : Plug-in power type (Sensitivity of microphone : -48 dB±3 dB (0 dB=1 V/Pa, 1 kHz)) Input impedance : Xấp xỉ 2 kΩ (unbalanced) Supply voltage : 2.5 V ±0.5 V [For line input] Input level : Xấp xỉ –10 dBV |
| Đầu ra âm thanh | ø3.5 mm stereo mini jack (Audio output is monaural.) Output impedance : Xấp xỉ 600 Ω (unbalanced) Output level : –20 dBV |
| External I/O Terminals | ALARM IN 1(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1), ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1), ALARM IN 3 (Alarm input 3/ AUX OUT) (x1) |
