| Image Sensor | Approx. 1/2.8 type CMOS image sensor |
| Scanning Area | 5.57 mm (H) × 3.13 mm (V) {7/32 inches (H) × 1/8 inches (V)} |
| Minimum Illumination | Color :
0.007 lx (30IRE, F1.3, 1/30s, AGC:11)*
0.009 lx (50IRE, F1.3, 1/30s, AGC:11)
0.0006 lx (50IRE, F1.3, 16/30s, AGC:11)*
BW :
0 lx (50IRE, F1.3, 1/30s, AGC:11, IR LED: On)
0.005 lx (50IRE, F1.3, 1/30s, AGC:11)
0.0004 lx (50IRE, F1.3, 16/30s, AGC:11)*
*Converted value |
| White Balance | ATW1/ ATW2/ AWC |
| Shutter Speed | [60 fps mode]
1/60 Fix to 1/10000 Fix
[30 fps/ 15 fps mode]
1/30 Fix to 1/10000 Fix
[50 fps mode]
1/50 Fix to 1/10000 Fix
[25 fps/ 12.5 fps mode]
1/25 Fix to 1/10000 Fix |
| Maximum Shutter | [60 fps mode]
Max. 1/4000 s to Max. 16/30 s
[30 fps/ 15 fps mode]
Max. 1/4000 s to Max. 16/30 s
[50 fps mode]
Max. 1/4000 s to Max. 16/25 s
[25 fps/ 12.5 fps mode]
Max. 1/4000 s to Max. 16/25 s |
| Intelligent Auto | On/Off |
| Super Dynamic | On/Off (Range : 0 to 31) |
| Dynamic Range | Max. 144 dB (Super Dynamic: On, Level: 31) |
| Adaptive Black Stretch | The level can be set in the range of 0 to 255. |
| Back Light Compensation/High Light Compensation | BLC (Back light compensation) / HLC (High light compensation) / Off (Range : 0 to 31)
*only when Super Dynamic/ Intelligent Auto: Off |
| Fog Compensation | On/Off (Range : 0 to 8)
*only when Intelligent Auto / Auto contrast adjust: Off |
| Maximum Gain (AGC) | The level can be set in the range of 0 to 11. |
| Color/BW (ICR) | Off/ On(IR Light Off)/ On(IR Light On)/
Auto1(IR Light Off)/ Auto2(IR Light On)/ Auto3(SCC) |
| IR Illumination | High/ Middle/ Low/ Off
Maximum irradiation distance:
70 m {Approx. 230 ft} (30IRE)*
50 m {Approx. 164 ft} (50IRE)
* Converted value |
| Digital Noise Reduction | The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) | On/ Off
4 areas available |
| Scene Change Detection (SCD) | On/ Off
1 area available |
| Audio Detection | On/ Off |
| AI Sound Classification | Selectable from Gunshot, Yell, Vehicle horn, Glass break |
| AI Anaytics | AI Video Motion Detection, AI Privacy Guard, AI Face Detection, AI People Detection, AI Vehicle Detection, AI Non mask Detection (prior to V3.30), AI Occupancy Detection, AI Scene Change Detection, AI On-site Learning, Ai Processing Relay |
| Privacy Zone | On/Off, Up to 8 zones available
Color: gray/white/blue/green/red/black, or mosaic |
| VIQS | On/Off
Up to 8 zones available |
| Image Rotation | 0° (Off)/ 90°/ 180° (Upside-down)/ 270° |
| Image Stabilizer | On/Off (Built-in gyro sensor)
Available only in the 30 fps mode |
| Camera Title (OSD) | On/Off
Up to 40 characters, Up to 2 lines (alphanumeric characters, marks) |
| Optical Zoom | 3.1x (Motorized zoom / Motorized Focus) |
| Extra Zoom | max 9.3x
(3.1x - 9.3x when resolution is 640x360) |
| Digital (electronic) Zoom | - |
| Focal Length | 2.9 mm – 9 mm
{1/8 inches – 11/32 inches} |
| Angular Field of View | [16:9 mode]
Horizontal： 36 ° (TELE) - 114 ° (WIDE)
Vertical： 20 ° (TELE) - 60° (WIDE)
[4:3 mode]
Horizontal： 27 ° (TELE) - 82 ° (WIDE)
Vertical： 20 ° (TELE) - 60° (WIDE) |
| Maximum Aperture Ratio | 1:1.3(WIDE) - 1:2.5(TELE) |
| Focus Range | 0.3 m {11-13/16 inches} - ∞ |
| Aperture Range | F1.3 - close |
| Safety | UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1 |
| EMC | FCC (Part15 ClassA), ICES-003 Issue 7 ClassA, EN55032 ClassA, EN55035 |
| Power Source/Power Consumption | [Power Source]
DC12 V, PoE+ (IEEE802.3at compliant)
[Power Consumption]
DC12 V ：1.2 A／ Approx. 14.2 W
PoE+ DC 54 V ：260 mA／ Approx. 14.0 W（Class 4 device） |
| Ambient Operating Temperature | -10 °C to +50 °C {14 °F to 122 °F}
(Power On range: 0 °C to 50 °C {32 °F to 122 °F}) |
| Ambient Operating Humidity | 10 % to 90 % (no condensation) |
| Shock Resistance | IK10(IEC 62262) |
| Dimensions | ø129.5 mm × 102.5 mm (H) {ø5-3/32 inches ×4-1/32 inches (H)}
Dome radius 41.5 mm {1-5/8 inches} |
| Mass (approx.) | Approx. 820 g {1.9 lbs} |
