| Image Sensor | Approx. 1/2.8 type CMOS image sensor |
| Scanning Area | 5.57 mm (H) × 3.13 mm (V)
{7/32 inches (H) × 1/8 inches (V)} |
| Minimum Illumination | Color :
0.011 lx (30IRE, F1.6, 1/30s, AGC:11)*
0.015 lx (50IRE, F1.6, 1/30s, AGC:11)
0.001 lx (50IRE, F1.6, 16/30s, AGC:11)*
BW :
0 lx (50IRE, F1.6, 1/30s, AGC:11, IR LED: On)
0.006 lx (50IRE, F1.6, 1/30s, AGC:11)
0.0004 lx (50IRE, F1.6, 16/30s, AGC:11)*
*Converted value |
| White Balance | ATW1 / ATW2 / AWC |
| Shutter Speed | [60fps mode] 1/60 Fix to 1/10000 Fix
[50fps mode] 1/50 Fix to 1/10000 Fix |
| Maximum shutter | 60 fps/30 fps/15 fps mode: Max.1/4000s to Max.16/30s
50 fps/25 fps/12.5 fps mode: Max.1/4000s to Max.16/25s |
| Intelligent Auto | On / Off |
| Super Dynamic | On / Off,
The level can be set in the range of 0 to 31. |
| Dynamic Range | Max.144 dB
(Super Dynamic : On, Level 31) |
| Adaptive Black Stretch | The level can be set in the range of 0 to 255. |
| Back Light Compensation/ High Light Compensation | BLC (Back light compensation) / HLC (High light compensation) / Off
The level can be set in the range of 0 to 31 (only when Super dynamic / Intelligent Auto :Off) |
| Fog Compensation | On / Off, The level can be set in the range of 0 to 8
(only when Intelligent auto / auto contrast adjust : Off) |
| Maximum Gain (AGC) | The level can be set in the range of 0 to 11. |
| Color/BW (ICR) | Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC) |
| IR LED Light | High/ Middle/ Low/ Off
Maximum irradiation distance:
350 m {Approx. 1150 ft} (30IRE)*
250 m {Approx. 820 ft} (50IRE)
*Converted value |
| Digital Noise Reduction | The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) | On / Off,
4 areas available |
| Scene Change Detection (SCD) | On / Off,
1 areas available |
| Audio Detection | On / Off |
| AI Sound Classification | Gunshot, Yell, Vehicle horn, Glass break |
| AI Analytics | AI Video Motion Detection, AI Face Detection,
AI People Detection, AI Vehicle Detection,
AI Non mask Detection (prior to V2.70), AI Occupancy Detection, AI Scene Change Detection |
| Privacy Zone | On / Off,
Up to 32 zones available |
| VIQS | On / Off,
Up to 8 zones available |
| Image Stabilizer | On / Off
(Built-in gyro sensor) |
| Camera Title (OSD) | On / Off,
Up to 40 characters (alphanumeric characters, marks) |
| Optical zoom | 40x (Motorized zoom / Motorized Focus) |
| Extra zoom | Max.60x
(40x-60x when resolution is 1280x720) |
| Digital (electronic) Zoom | 60x - 640x |
| Focal length | 4.25 - 170 mm {5/32 inches - 6-11/16 inches} |
| Angular Field of View | [16 : 9 mode] Horizontal : 2.0° (TELE) – 65° (WIDE), Vertical : 1.2° (TELE) – 39° (WIDE)(TBD)
[ 4 : 3 mode] Horizontal : 1.5° (TELE) – 51° (WIDE), Vertical : 1.2° (TELE) – 39° (WIDE)(TBD) |
| Maximum Aperture Ratio | 1 : 1.6 (WIDE) – 1 : 4.95 (TELE) |
| Focus range | 3.0 m {118-1/8 inches} –∞ |
| Aperture range | F1.6 - close |
| Panning Range | 360° Endless Panning |
| Panning Speed | Manual ：Approx. 0.065 °/s – 150 °/s (PoE++), Approx. 0.065 °/s – 90 °/s (PoE+)
Preset ：Up to 700 °/s (PoE++), Up to 90 °/s (PoE+) |
| Tilting Range | Operational -20° – +90° |
| Tilting Speed | Manual ：Approx. 0.065 °/s – 150 °/s (PoE++), Approx. 0.065 °/s – 90 °/s (PoE+)
Preset ：Up to 500 °/s (PoE++), Up to 90 °/s (PoE+) |
| Preset Positions | 256 positions |
| Auto Mode | Auto track/ Auto pan/ Preset sequence/ Patrol |
| Self Return | 10 s/ 20 s/ 30 s/ 1 min/ 2 min/ 3 min/ 5 min/ 10 min/ 20 min/ 30 min/ 60 min |
| Active ClearSight | Yes |
