Sensor | 1/2.7″, 8.0 megapixel, progressive scan, CMOS |
Lens | 2.8mm@F2.0 | 4.0mm@F2.0 |
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
2.8 | 84.0 | 33.6 | 16.8 | 8.4 |
Angle of View (H) | 112.4° | 86.5° |
Angle of View (V) | 60.1° | 44.1° |
Angle of View (O) | 146.1° | 112.5° |
Adjustment angle | Pan: 0° ~ 360° | Tilt: 0° ~ 90° | Rotate: 0° ~ 360° |
Shutter | Auto/Manual, 1 ~ 1/100000s |
Minimum Illumination | Colour: 0.01Lux (F2.0, AGC ON) 0Lux with IR on |
Digital noise reduction | 2D/3D DNR |
Day/Night | IR-cut filter with auto switch (ICR) |
S/N | >56dB |
IR Range | Up to 30m (98 ft) IR range |
Wavelength | 850nm |
IR On/Off Control | Auto/Manual |
Defog | Digital Defog |
WDR | 120dB |
Video |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
H.264 code profile | Baseline profile, Main profile, High profile |
Frame Rate | Main Stream: 8MP (3840*2160), Max 20fps; 5MP (3072*1728), Max 30fps; 4MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 1080P (1920*1080), Max 30fps;720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
Video Bit Rate | 128 Kbps~16 Mbps |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 4 areas |
ROI | Up to 8 areas |
Motion Detection | Up to 4 areas |
Image |
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Digital Noise Reduction | 2D/3D DNR |
Smart IR | Support |
Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
Dewarping | Supported |
HLC | Supported |
BLC | Supported |
Audio |
Audio Compression | G.711 |
Two-way audio | Supported |
Suppression | Supported |
Sampling Rate | 8KHZ |
Storage |
Edge Storage | Micro SD, up to 256GB |
Network Storage | ANR |
Network |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, SNMP, HTTPS, SMTP, SSL |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
Client | EZStation EZView EZLive |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
Interface |
Network | 1 RJ45 10M/100M Base-TX Ethernet |
Built-in Mic | Supported |
Built-in Speaker | Supported |
Alarm Light | Supported |
Certifications |
Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
General |
Power | DC 12V±25%, PoE (IEEE 802.3af) |
Power consumption: Max 10.5W |
Dimensions (L × W × H) | 191× 75 × 74mm (7.5” × 3.0” × 2.9”) |
Net Weight | 0.41kg (0.90lb) |
Material | Metal |
Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Surge Protection | 2KV |
Ingress Protection | IP67 |
Reset Button | Supported |
| | | | | | | | |
