Sensor | 1/1.8″, 4.0 megapixel, progressive scan, CMOS |
Lens | 4mm@F1.6, fixed zoom lens | 6mm@F1.6, fixed zoom lens |
Iris | Fix aperture |
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
6 | 90.0(295.3ft) | 36.0(118.1ft) | 18.0(59.1ft) | 9.0(29.5ft) |
Angle of View (H) | 94.7° | 68.1° |
Angle of View (V) | 49.6° | 41.6° |
Angle of View (O) | 116.5° | 83.8° |
Shutter | Auto/Manual, 1 ~ 1/100000s |
Min. Illumination | Colour:0.001lux (F1.6, AGC ON) 0 lux with IR |
WDR | 120dB |
Day/Night | IR-cut filter with auto switch (ICR) |
S/N | >55dB |
IR Range | Up to 50m (164 ft) IR range |
Wavelength | 850nm |
IR On/Off Control | Auto/Manual |
Defog | Digital Defog |
Video |
Video Compression | Ultra 265,H.265,H.264,MJPEG |
Frame Rate | Main Stream: 4MP(2688*1520),Max 30fps; 4MP(2560*1440),Max 30fps; 2MP(1920*1080),Max 30fps; Sub Stream: 2MP (1920*1080), Max 30fps; Third Stream: D1 (720*576), Max 30fps |
Video Bit Rate | 128 Kbps~16 Mbps |
ROI | Supported |
Video stream | Triple streams |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 8 areas(8 blacks/4 mosaics+4 blacks) |
Image |
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Digital noise reduction | 2D/3D DNR |
Smart IR | Support |
Flip | Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
HLC | Support |
BLC | Support |
Smart |
General Function | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
Audio |
Audio Compression | G.711U,G.711A |
Two way audio | Supported |
Sampling Rate | 8KHZ |
Storage |
Edge Storage | Micro SD, up to 256 GB |
Network Storage | ANR,NAS(NFS) |
Network |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
Client | EZStation Ezview EZLive |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
Interface |
Audio I/O | Audio cable |
1 Input: impedance 35kΩ; amplitude 2V [p-p] |
1 output: impedance 600Ω; amplitude 2V [p-p] |
Alarm I/O | 1/1 |
Network | 1 x RJ45 10M/100M Base-TX Ethernet |
Certifications |
Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
General |
Power | DC12V(±25%), PoE(IEEE802.3af) |
Power consumption: Max 8.5W |
Support overcurrent protection and input short circuit protection |
Dimensions (Ø x H) | Φ245.6×85.7×85.4mm(Φ12.1″ x 3.4″ x 3.4″) |
Net Weight | 0.90kg(1.98lb) |
Material | Metal |
Working Environment | -40°C ~ 60°C (-40°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Storage Environment | -40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing) |
Surge protection | 6KV |
Vandal Resistant | IK10 |
Ingress Protection | IP67 |
| | | | | | |
