| Sensor | 1/1.8″, 2.0 megapixel, progressive scan, CMOS |
| Lens | 6.5 ~ 143 mm, AFautomaticfocusing andmotorizedzoomlens |
| Digital Zoom | 16 |
| Optical Zoom | 22 |
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
| 6.5 | 78 | 31.2 | 15.6 | 7.8 |
| 143 | 1716 | 686.4 | 343.2 | 171.6 |
| Angle of View (H) | 57.2° ~ 3.3° |
| Angle of View (V) | 38.4° ~ 1.3° |
| Angle of View (O) | 70.4° ~ 3.9° |
| Shutter | Auto/Manual; shutter time: 1 ~ 1/100000s |
| Minimum Illumination | Colour: 0.0005Lux (F1.5, AGC ON)
0Lux with IR on |
| Iris | Auto/Manual; F1.5 ~ F3.4 |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >52dB |
| IR Range | Up to 200 m (656ft),
While Light, up to 30m |
| Defog | Digital Defog |
| WDR | 120dB |
| Video |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream: 2MP (1920*1080), Max 60fps;
Sub Stream: 2MP (1920*1080), Max 60fps;
Third Stream: D1 (720*576), Max 60fps |
| HLC | Supported |
| BLC | Supported |
| EIS | Supported |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 24 areas |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| Smart |
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio |
| Audio Compression | G.711 |
| Two-way audio | Supported |
| Suppression | Supported |
| Sampling Rate | 8KHZ |
| Storage |
| Edge Storage | Micro SD, up to 256GB |
| Network Storage | ANR |
| Network |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
| Pan & Tilt |
| Pan Range | 360° (endless) |
| Pan Speed | 0.1°/s ~ 240°/s |
| Preset speed: 300°/s |
| Tilt Range | -15° ~ 90° (auto reverse) |
| Tilt Speed | 0.1° ~ 160°/s |
| Preset speed: 240°/s |
| Number of Preset | 1024 |
| Patrol | Preset patrol, route patrol, recorded patrol |
| Home Position | Supported |
| Drag-to-Zoom | Supported |
| Interface |
| Audio I/O | Audio cable |
| 1 Input: impedance 35kΩ; amplitude 2V [p-p] |
| 1 Output: impedance 600Ω; amplitude 2V [p-p] |
| Alarm I/O | 2/1 |
| Serial Port | 1 RS485 |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| Video Output | 1 BNC, impedance 75Ω; amplitude 1V [p-p] |
| General |
| Power | AC 24V (Default)±25%, DC 24V±25% |
| Power consumption: 12 ~ 46W |
| Dimensions (Ø x H) | Ø227 x 359.4mm (Ø8.9” x 14.2”) |
| Weight | 5.4kg (11.9lb) |
| Working Environment | -40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing) |
| Ingress Protection | IP66 |
| Reset Button | Supported |
