SYSTEM |
Main Processor | ARM Processor |
Operating System | Embedded LINUX |
ONVIF Compliance | ONVIF Profile S |
User Management | User Level: Administrator, Regular User |
Log | System, Recording, User |
Date & Time | Time Zone, Manual, Automatic Sync NTP, Daylight Saving Time |
Fan | Yes |
Security | Encrypted streaming and control |
VIDEO |
Inputs | 8 channels |
AUDIO |
Audio Input/Output | 3.5 mm Line in x1
3.5 mm Line out x1 |
Two-way Communication | Supported |
Audio Format | G.711 |
DISPLAY |
Interface | HDMI x 1 (4K Max), VGA x 1 (1080 P) |
Resolution | 3840 x 2160, 1920 x 1080, 1280 x 1024,1024 x 768 |
Display Split | 1 x 1, 2 x 2, 3 x 3, 1 + 7, customs |
OSD | Time OSD, channel OSD |
Stream Application | 1x1: 1 ch 4 K MAX 2x2: 2 MP in, 4x1080 P 2x2: >2 MP, Camera Stream 2 3x3: Camera Stream 2 |
PTZ Operation | Direction control, home, iris, preset, patrol |
VIDEO DETECTION AND ALARMS |
Event | Camera: Camera Alarm In, Motion Detection, Camera Disconnection, Tampering Detection, Smart Motion Detection, Intrusion, Crowd Detection, Multi-Loitering System: System Alarm In/Out, Disk Failure, Disk Full |
Event Action | Video Recording, Send Email, Buzzer, FTP, Camera Alarm Out, PTZ-Preset, System Alarm Out,Send Video to Full Screen |
Alarm Input | 8 |
Alarm Out | 1 |
RECORDING |
Compression | H.265 HEVC smart codec/H.264 |
Resolution | Up to 3840 x 2160 |
Frame Rate | 30 fps |
Recording Mode | Continuous, Manual, Event |
Max Pre-Event Recording Buffer Size | Main Stream: 8 Mbps
Sub Stream: 4 Mbps |
Post-Event Recording Interval | 30 s (Max. 60 s) |
Recording Stream | Support main stream and sub stream simultaneous recording |
Recording Throughput | 64 Mbps |
STORAGE |
Internal HDD Slots | Internal x2 (3.5 inch) |
HDD Max. Capacity | 10 TB |
Manual Backup | USB Dongle (FAT Format) |
PLAYBACK AND BACKUP |
Sync Playback | 8 channels |
Decoding | H.265/H.264: 3840 X 2160 @ 30 fps (1-CH), 2560 * 1920 @ 30 fps (1-CH), 1920 X 1080 @ 120 fps (4-CH), 720 X 576 @ 240 fps (8-CH) |
Search Mode | Time search ,Event Search, Video clip |
Playback Function | Regular (Play, Pause, Stop), Play Backwards, Next Frame, Go Back 30 Seconds, Go Forward 30 Seconds, Speed Control, Timeline, Timeline Scale,Digital Zoom, Snapshot, Back Up |
Snapshot | JPEG |
ENVIRONMENTAL |
Operating Temperature | -10°C ~ 55°C (14°F ~ 131°F) |
Relative Humidity | Less than 90% RH |
Storage Temperature | –40°C ~ 60°C (-40°F ~ 140°F) |
ELECTRICAL |
Power Supply | 100-240V AC, 50/60 Hz |
Power Consumption | Max. 180 W;
15W without HDD
PoE Ports Output Power: 130W max. (30W max. for a single port) |
NETWORK |
Ethernet | 10/100/1000 Mbps Ethernet (RJ-45) x 1 |
PoE | 802.3at/af compliant PoE ports x 8 |
Supported Protocols | IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter, P2P |
Maximum Number of Users | 16 |
Network Throughput | 64 Mbps |
Smart Phone Compatibility | IOS 11 or later and Android 5.0 or later support |
Browsers | Edge, Chrome, Firefox, Safari |
AUXILIARY INTERFACE |
USB Ports | Front x2, usb 2.0; Back x1, usb 2.0 |
PHYSICAL |
Dimensions | 372.0 × 313.3 × 46.5 mm |
Weight (Without HDD) | 2.65 kg without HDD |
REGULATORY |
Emissions | FCC Part 15, CE (EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-6-4), ICES-003, Comply with UKCA and RCM |
Immunity | CE(EN 50130-4, EN 55024, EN 55035) Comply with UKCA and RCM |
Safety | UL LISTED TO UL/CSA 62368-1, CE(EN 62368-1), Comply with UKCA and RCM |
RoHS | CE(EN 63000), UAE(Cabinet Decree No.10 of 2017) |
