SYSTEM |
Main Processor | ARM Processor |
Operating System | Embedded LINUX |
ONVIF Compliance | ONVIF Profile S |
User Management | User Level: Administrator, Regular User |
Log | System, Recording, User |
Date & Time | Time Zone, Manual, Automatic Sync NTP, Daylight Saving Time |
Fan | No |
Security | Encrypted streaming and control |
VIDEO |
Inputs | 32 channels |
AUDIO |
Audio Input/Output | 3.5 mm Line in x1
3.5 mm Line out x1 |
Two-way Communication | Supported |
Audio Format | G.711 |
DISPLAY |
Interface | HDMI x 2, VGA x 1 (1080 P) |
Resolution | 3840 x 2160, 1920 x 1080, 1280 x 1024,1024 x 768 |
Display Split | 1 x 1, 2 x 2, 3 x 3, 4 x 4, 6 x 6, 1 + 7, 4 + 28, customs |
OSD | camera title, time, custom OSD, PTZ position |
Stream Application | 1 X 1: 1 ch 12 MP MAX 2 x 2: 4 ch 4 MP 3 x 3: 9 ch 2 MP 6 x 6: 32 ch D1 |
PTZ Operation | Direction control, Home, Iris, Preset, Patrol (group), Focus +/- Zoom +/- |
VIDEO DETECTION AND ALARMS |
Event | Camera: Camera alarm in, (Smart) motion detection, Video loss, Camera tamper, Intrusion, Multi loitering, Crowd detection System: NVR alarm in/out, Disk failure, Disk full, IP address conflict, Network disconnect, Intrusion |
Event Action | Video Recording, Send Email, Buzzer, FTP, Camera Alarm Out, PTZ-Preset, System Alarm Out,Send Video to Full Screen |
Alarm Input | 6 |
Alarm Out | 2 |
RECORDING |
Compression | H.265 HEVC smart codec/H.264 |
Resolution | Up to 3840 x 2160 |
Frame Rate | 30 fps |
Recording Mode | Continuous, Manual, Event |
Max Pre-Event Recording Buffer Size | Main stream: 8 Mbps Sub stream: 4 Mbps |
Post-Event Recording Interval | 30 s (Max. 60 s) |
Recording Stream | Support main stream and sub stream simultaneous recording |
Recording Throughput | 320 Mbps |
STORAGE |
Internal HDD Slots | Internal x4 (3.5 inch) |
HDD Max. Capacity | 10 TB |
Manual Backup | USB Dongle (FAT Format) |
PLAYBACK AND BACKUP |
Sync Playback | 16 channels |
Decoding | H.265/H.264: 3840 X 2160 @ 30 fps (1-CH), 2560 * 1920 @ 120 fps (4-CH), 1920 X 1080 @ 270 fps (9-CH), 720 X 576 @ 960 fps (32-CH) |
Search Mode | Time search ,Event Search, Video clip |
Playback Function | Regular (Play, Pause, Stop), Play Backwards, Next Frame, Go Back 30 Seconds, Go Forward 30 Seconds, Speed Control, Timeline, Timeline Scale,Digital Zoom, Snapshot, Back Up |
Snapshot | JPEG |
ENVIRONMENTAL |
Operating Temperature | -10°C ~ 55°C (14°F ~ 131°F) |
Relative Humidity | Less than 90% RH |
Storage Temperature | –40°C ~ 60°C (-40°F ~ 140°F) |
ELECTRICAL |
Power Supply | 100-240V AC, 50/60 Hz |
Power Consumption | Max. 300 W; 15 W without HDD PoE Ports Output Power: 140W max. (30W max. for a single port) |
NETWORK |
Ethernet | 10/100/1000Mbps Ethernet (RJ-45) x 2 |
PoE | 802.3at/af compliant PoE ports x 16 |
Supported Protocols | IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter, P2P |
Maximum Number of Users | 16 |
Network Throughput | 320 Mbps |
Smart Phone Compatibility | IOS 11 or later and Android 5.0 or later support |
Browsers | Edge, Chrome, Firefox, Safari |
AUXILIARY INTERFACE |
USB Ports | Front x2, USB2.0; Back x1,USB2.0 |
PHYSICAL |
Dimensions | 440.0 × 376.2 × 70.0 mm (17.32 × 14.81 × 2.76 inch) |
Weight (Without HDD) | 4.65 kg (10.25 lb) without HDD |
REGULATORY |
Emissions | FCC Part 15, CE (EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000-6-4), ICES-003, Comply with UKCA and RCM |
Immunity | CE(EN 50130-4, EN 55024, EN 55035) Comply with UKCA and RCM |
Safety | UL LISTED TO UL/CSA 62368-1, CE(EN 62368-1), Comply with UKCA and RCM |
RoHS | CE(EN 63000), UAE(Cabinet Decree No.10 of 2017) |
