SYSTEM |
Main Processor | ARM Processor |
Operating System | Embedded LINUX |
ONVIF Compliance | ONVIF Profile S |
User Management | User level: Administrator, Regular user |
Log | System, Recording, User |
Date & Time | Time Zone, Manual, Automatic Sync NTP, Daylight Saving Time |
Fan | Yes |
Security | Encrypted streaming and control |
Encryption Chipset | Hardware embedded |
VIDEO |
Inputs | 32 channels |
AUDIO |
Audio Input/ Output | 3.5 mm Line in x1 3.5 mm Line out x1 |
Two-way Communication | Supported |
Audio Format | G.711 |
DISPLAY |
Interface | HDMI 1 (4K Max), HDMI 2 (1080P), VGA x1 (1080P) |
Resolution | 3840 x 2160, 1920 x 1080, 1280 x 1024, 1024 x 768 |
Display Split | 1/4/9/16/32 |
OSD | Time OSD, channel OSD |
Stream Application | 1 X 1: 1 ch 12 MP MAX 2 x 2: 4 ch 4 K 4 x 4: 16 ch 2 MP 32: 32ch D1 |
Fisheye Dewarp | NO |
PTZ Operation | Direction control, Home, Iris, Preset, Patrol (group), Focus +/- Zoom+/- |
RECORDING |
Compression | H.265/H.264 |
Resolution | Up to 3840 x 2160 |
Frame Rate | 30 fps |
Recording Mode | Continuous, Manual, Event |
Pre-Event Recording Interval | Main stream: 2 Mbps Sub stream: 1 Mbps |
Post-Event Recording Interval | 30 s (Max. 60 s) |
Recording Stream | Camera Stream 1 Camera Stream 2 |
Recording Throughput | up to 320 Mbps |
VIDEO DETECTION AND ALARMS |
Event | Camera: Camera Alarm In, Motion detection, Camera disconnection,Tampering detection System: System Alarm in/out, Disk failure, Disk full, VA (SMD/intrusion/crowd/ Multi loitering detection) |
Event Action | Video recording, Send email, Buzzer, FTP, Camera Alarm Out, PTZ-Preset, System Alarm Out,Send video to full screen |
Alarm Input | 16 |
Alarm Out | 6 |
RS485 | Supported |
RS232 | Supported |
e-SATA | Supported |
STORAGE |
Internal HDD | Internal x8 (3.5") |
HDD Max. Capacity | 10 TB |
Manual Backup | USB Dongle (FAT Format) |
RAID | RAID* 1/5/6 |
PLAYBACK AND BACKUP |
Sync Playback | 16 channels |
Decoding | H.265/H.264: 4000 x 3000 @ 30 fps (1-CH) 3840 x 2160 @ 120 fps (4-CH) 720 x 576 @ 480 fps (16-CH) |
Search Mode | Time search, Event Search, video clip |
Playback Function | Regular (play, pause, stop), play backwards, next frame, Go back 30 seconds, Go forward 30 seconds, speed control, timeline, timeline scale,Digital zoom, snapshot, back up |
Snapshot | JPG |
NETWORK |
Ethernet | 10/100/1000 Mbps Ethernet (RJ-45) x 2 |
Supported Protocols | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP (Secure), DNS, DDNS, IP Filter, P2P, SNMP |
Maximum Number Of Users | 16 |
Network Throughput | up to 320 Mbps |
Smart Phone Compatibility | IOS 11 or later and Android 5.0 or later support |
Browsers | Edge, Chrome, Firefox, Safari |
AUXILIARY INTERFACE |
USB Ports | Front x 2, USB 2.0, Back x 1, USB 3.0 |
ELECTRICAL |
Power Supply | 100-240V AC, 50/60 Hz |
Power Consumption | Max. 200 W; 15W without HDD HN356408xxDR: Max. 550 W; 15W without HDD |
ENVIRONMENTAL |
Operating Temperature | -10°C ~ 55°C (14°F ~ 131°F) |
Relative Humidity | Less than 90% RH |
Storage Temperature | –40°C to 60°C (-40°F ~ 140°F) |
PHYSICAL |
Dimensions | 440 × 426 × 100 mm (17.32 × 16.77× 3.94 inch) |
Weight (Without HDD) | 7 kg (15.43 lb) without HDD |
REGULATORY |
Emissions | FCC Part 15, CE (EN 55032, EN 61000-3-2, EN 61000-3-3, EN 61000- 6-4), ICES-003, Comply with UKCA and RCM |
Immunity | CE (EN 50130-4, EN 55035) Comply with UKCA and RCM |
Safety | UL LISTED TO UL/CSA 62368-1, CE(EN 62368-1), Comply with UKCA and RCM |
RoHS | CE(EN 63000), UAE (Cabinet Decree No.10 of 2017) |
