| Cảm biến hình | 1/1.8 type CMOS image sensor |
| Cường độ ánh sáng nhỏ nhất | Color : 0.09 lx, BW : 0.05 lx (F1.5, Maximum shutter : Off (1/30s), AGC : 11) BW : 0 lx (F1.5, Maximum shutter : Off (1/30 s), AGC : 11, when the IR LED is lit) Color : 0.006 lx, BW : 0.003 lx (F1.5, Maximum shutter : max. 16/30s, AGC : 11) |
| Cân bằng trắng | ATW1, ATW2, AWC |
| Tốc độ màn trập | 1/30 Fix to 1/10000 Fix |
| Intelligent Auto | On / Off |
| Super Dynamic | On / Off, the level can be set in the range of 0 to 31. |
| Dải tần nhạy sáng | Max 120 dB (Super Dynamic : On, Level : 31) |
| Bù sáng | BLC (Back light compensation) / HLC (High light compensation) / Off The level can be set in the range of 0 to 31. (only when Super dynamic / Intelligent Auto : Off) |
| Bù sương mù | On / Off, The level can be set in the range of 0 to 8 (only when Intelligent auto / auto contrast adjust : Off) |
| AGC | The level can be set in the range of 0 to 11. |
| Color/BW (ICR) | Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC) |
| Đèn LED | High / Middle / Low / Off, Maximum irradiation distance : 40 m {Xấp xỉ 131 ft} |
| Giảm nhiễu động | The level can be set in the range of 0 to 255. |
| Phát hiện chuyển động | On / Off, 4 areas available |
| Intelligent VMD (i-VMD) | Type6 Bundled License |
| Xoay hình | 0 ° (Off) / 90 °/ 180 ° (Upside-down)/ 270 ° |
| OSD | On / Off Up to 20 characters (alphanumeric characters, marks) |
| Tỷ lệ zoom | 2x Optical zoom (Motorized zoom / Motorized focus) |
| Zoom tự động | Choose from 3 levels of x1, x2, x4 |
| Độ dài tiêu cự | 4.3 mm – 8.6 mm {5/32 inches – 11/32 inches} |
| Tỷ lệ khẩu độ | 1 : 1.5 (WIDE) – 1 : 2.4 (TELE) |
| Phạm vi tiêu điểm | 1 m {39-3/8 inches} – ∞ |
| Góc nhìn | [16 : 9 mode] Horizontal : 52° (TELE) – 101° (WIDE) Vertical : 29° (TELE) – 55° (WIDE) |
| Tùy chỉnh góc | Horizontal (PAN) angle : ±180°, Vertical (TILT) angle : -30 to +85°, Azimuth (YAW) angle : ±100° |
| Kiểm soát hình ảnh | Brightness, AUX On / Off |
| Âm thanh | Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High Audio Output : On / Off Volume adjustment : Low / Middle / High |
| GUI/Cài đặt ngôn ngữ | English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Network IF | 10Base-T / 100Base-TX, RJ45 connector |
| Độ phân giải H.265 | [16 : 9 mode] 3840×2160, 2560×1440, 1920×1080, 1280×720, 640×360, 320×180 |
| H.265/H.264 | [Transmission Mode] Constant bit rate / VBR / Frame rate / Best effort [Transmission Type ] Unicast / Multicast |
| JPEG | [Image Quality] 10 steps |
| Mã hóa thông minh | GOP (Group of pictures) control : On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off *On (Frame rate control) and On (Advanced) are only available with H.265. Auto VIQS : On / Off |
| Nén âm thanh | G.726 (ADPCM) : 16 kbps / 32 kbps G.711 : 64 kbps AAC-LC : 64 kbps / 96 kbps / 128 kbps |
| Truyền âm thanh | Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex) |
| Giao thức hỗ trợ | IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, RTP, FTP, SMTP, DNS, NTP, SNMP, DHCPv6, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, LLDP, SRTP, SSL/TLS IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, FTP, SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, LLDP, SRTP, SSL/TLS |
| Số người dùng tối đa | Up to 14 users (Depends on network conditions) |
| Thẻ nhớ SDXC/SDHC/SD | H.265 / H.264 recording : Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure JPEG recording : Manual REC / Alarm REC (Pre/Post) / Backup upon network failure Compatible SDXC/SDHC/SD Memory Card : Panasonic 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64 GB**, 128 GB**, 256 GB**model *SDHC card, ** SDXC card (except miniSD card and microSD card) |
| Thiết bị di động tương thích | iPad, iPhone, Android TM mobile terminals |
| Nguồn cảnh báo | 3 terminals input, VMD alarm, Command alarm |
| Cảnh báo | SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification, Indication on browser, FTP image transfer, Panasonic alarm protocol output |
| Đầu ra hình | VBS : 1.0 V [p-p] / 75 Ω, composite, ø3.5 mm mini jack An NTSC or PAL signal can be outputted from camera |
| Đầu vào âm thanh | ø3.5 mm stereo mini jack [For microphone input] Recommended applicable microphone : Plug-in power type (Sensitivity of microphone : -48 dB±3 dB (0 dB=1 V/Pa, 1 kHz)) Input impedance : Xấp xỉ 2 kΩ (unbalanced) Supply voltage : 2.5 V ±0.5 V [For line input] Input level: Xấp xỉ –10 dBV |
| Đầu ra âm thanh | ø3.5 mm stereo mini jack (Audio output is monaural.) Output impedance : Xấp xỉ 600 Ω (unbalanced) Output level : –20 dBV |
| External I/O Terminals | ALARM IN 1(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1) ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1) , ALARM IN 3 (Alarm input 3/ AUX OUT) (x1)saft |
| Độ an toàn | UL (UL60950-1), c-UL (CSA C22.2 No.60950-1), CE, IEC60950-1 |
| EMC | FCC (Part15 ClassA), ICES003 ClassA, EN55032 ClassB, EN55024 |
| Nguồn điện và mức tiêu thụ | DC power supply : DC12 V 880 mA/ Xấp xỉ 10.6 W PoE (IEEE802.3af compliant) Device : DC48 V 230 mA/ Xấp xỉ 11.0 W (Class 0 device) |
| Nhiệt độ hoạt động | -40 °C to +60 °C (-40 °F to 140 °F) (Power On range : –30 °C to +60 °C {–22 °F to 140 °F}) |
| Độ ẩm hoạt động | 10 to 100 % (no condensation) |
| Chống nước và bụi | IP66 (IEC60529), Type 4X(UL50E), NEMA 4X compliant |
| Chống sốc | 50J (IEC 60068-2-75 compliant), IK10 (IEC 62262) |
| Chống gió | Up to 40 m/s {Xấp xỉ 89 mph} |
| Kích thước | When using base bracket : ø164 mm × 139 mm (H) {ø6-15/32 inches × 5-15/32 inches (H)} Dome radius 42 mm {1-21/32 inches} When using attachment plate only : ø154 mm × 103 mm (H) {ø6-1/16 inches × 4-1/16 inches (H)} Dome radius 42 mm {1-21/32 inches} |
| Trọng lượng | When using base bracket : Xấp xỉ 1.6 kg {3.53 lbs} When using attachment plate only : Xấp xỉ 1.2 kg {2.65 lbs} |
