| Cảm biến hình | Xấp xỉ. 1/2.8 type CMOS |
| Cường độ ánh sáng nhỏ nhất | Color : 0.05 lx (-V3LG : 0.15 lx)(30IRE, F1.3, 1/30s) Color : 0.07 lx (-V3LG : 0.20 lx)(50IRE, F1.3, 1/30s) BW : 0.04 lx (-V3LG : 0.12 lx)(50IRE, F1.3, 1/30s) BW : 0 lx (50IRE, F1.3, 1/30s with IR LED) |
| Cân bằng trắng | ATW1 / ATW2 / AWC |
| Tốc độ màn trập | [30fps/15fps mode] 1/30 Fix to 1/10000 Fix [25fps/12.5fps mode] 1/25 Fix to 1/10000 Fix |
| i-PRO Tự động điều chỉnh ánh sáng | On / Off |
| i-PRO Super Dynamic*3 | On / Off, The level can be set in the range of 0 to 31. |
| Dải tần nhạy sáng | Max.132 dB (Super Dynamic : On, Level 31) |
| ABS | The level can be set in the range of 0 to 255. |
| Cân bằng ánh sáng | BLC (Back light compensation) / HLC (High light compensation) / Off (khi Super dynamic / Tự động điều chỉnh ánh sáng : Off) |
| Chống sương | On / Off (khi Tự động điều chỉnh ánh sáng / tự động điều chỉnh độ tương phản : Off) |
| AGC | The level can be set in the range of 0 to 11. |
| Color/BW (ICR) | Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC) |
| Đèn LED | High / Middle / Low / Off, Maximum irradiation distance : 40 m {Xấp xỉ. 131 ft} (30IRE) , 30 m {Xấp xỉ. 98 ft} (50IRE) |
| Giảm nhiễu tự động | The level can be set in the range of 0 to 255. |
| Phát hiện chuyển động(VMD) | On / Off, 4 areas available |
| Scene Change Detection | On / Off, 1 areas available |
| Phát hiện âm thanh | On / Off |
| Phân loại âm thanh cơ bản | Gunshot, Yell, Vehicle horn, Glass break |
| Phân tích AI | Yes |
| Vùng bảo mật | On / Off, Up to 8 zones available |
| VIQS | On / Off, Up to 8 zones available |
| Xoay hình*4 | 0 ° / 90 ° / 180 ° / 270 ° |
| OSD | On / Off, Up to 40 characters (alphanumeric characters, marks) |
| Tùy chỉnh lấy nét | Auto focus / Manual |
| Zoom quang học | 3.1 x (Motorized zoom / Motorized Focus) |
| Zoom mở rộng | 3.1x – 9.3x (độ phân giải640 x 360) |
| Focal Length | 2.9 – 9 mm {1/8 inches – 13/32 inches} |
| Góc nhìn | [16 : 9 mode] Horizontal : 33° (TELE) – 105° (WIDE), Vertical : 19° (TELE) – 56° (WIDE) [ 4 : 3 mode] Horizontal : 33° (TELE) – 105° (WIDE), Vertical : 25° (TELE) – 76° (WIDE) |
| Khẩu độ tối đa | 1 : 1.3 (WIDE) 1 : 2.5 (TELE) |
| Focusing Range | 0.3 m {11-13/16 inches} – ∞ |
| Phát hiện (25ppm / 8ppt) | Wide: 47.1 m /154.7 ft, Tele: 207.4 m / 680.5 ft |
| Quan sát (62.5ppm / 19ppt) | Wide: 18.9 m / 61.9 ft, Tele: 83.0 m / 272.2 ft |
| Nhận biết (125ppm / 38ppt) | Wide: 9.4 m / 30.9 ft, Tele: 41.5 m / 136.1 ft |
| Xác định (250ppm / 76ppt) | Wide: 4.7 m / 15.5 ft, Tele: 20.7 m / 68.1 ft |
| Chip (SoC) | Ambarella CV22 |
| Adjusting Angle | Horizontal : -240 to +120°, Vertical : -30 to +85°, Yaw : ±100° |
| Camera Control | Brightness, AUX On / Off |
| Âm thanh | Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High Đầu ra âm thanh : On / Off Volume adjustment : Low / Middle / High |
| GUI / Cài đặt ngôn ngữ | English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese |
| Network IF | 10Base-T / 100Base-TX, RJ45 connector |
| Độ phân giải H.265/ H.264/ JPEG (MJPEG) | [16:9 mode (30 fps mode)][16:9 mode (25 fps mode)] 3072×1728/2560×1440/1920×1080/1280×720/640×360/320×180 [4:3 mode (30 fps mode)][4:3 mode (25 fps mode)] 3072×2304/2560×1920/1280×960/800×600/VGA/400×300/320×240 |
| JPEG – Chất lượng hình ảnh | 10 steps |
| i-PRO Mã hóa thông minh | GOP (Group of pictures control): Off/ Low (Variable GOP 1s-8s)/ Mid (Variable GOP 4s-16s)/ Advanced(Fixed GOP 60s w/1s key-frame)/ Frame rate control (Variable GOP 4s-16s with frame rate control) *Advanced and Frame rate control are only available with H.265. Smart VIQS: On(High)/On(Low)/Off, Smart P-picture control: On/Off |
| Nén âm thanh | G.726 (ADPCM) : 16 kbps / 32 kbps G.711 : 64 kbps AAC-LC : 64 kbps / 96 kbps / 128 kbps |
| Truyền âm thanh | Off / Mic (Line) input / input audio /Interactive (Half duplex) / Interactive (Full duplex) |
| Hỗ trợ giao thức | IPv6: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, SMTP, DNS, NTP, SNMPv1/v2/v3, DHCPv6, RTP, MLD, ICMP, ARP, IEEE 802.1X, DiffServ, SFTP, MQTT, LLDP IPv4: TCP/IP, UDP/IP, HTTP, HTTPS, SSL/TLS, RTSP, RTP, RTP/RTCP, SMTP, DHCP, DNS, DDNS, NTP, SNMPv1/v2/v3, UPnP, IGMP, ICMP, ARP, IEEE 802.1X, DiffServ, SRTP, SFTP, MQTT, LLDP |
| Số người dùng tối đa cùng thời điểm | Up to 14 users (Depends on network conditions) |
| Bảo mật | FIPS 140-2 level3 |
| SDXC/SDHC/SD Tùy chọn thẻ nhớ | H.265 / H.264 recording : Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure JPEG recording : Manual REC / Alarm REC (Pre/Post) / Backup upon network failure Compatible SDXC/SDHC/SD Memory Card : microSDXC memory card: 64 GB, 128 GB, 256 GB, 512 GB microSDHC memory card: 4 GB, 8 GB, 16 GB, 32 GB microSD memory card: 2 GB |
| Thiết bị di động tương thích | iPad, iPhone, AndroidTM terminals |
| Nguồn báo động | 3 terminals input, VMD alarm, Command alarm, Audio detection alarmb |
| Hình thức báo động | SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification Indication on Trình duyệt, TCP alarm notification output |
| Monitor Output (for Adjustment) | VBS : 1.0 V [p-p] / 75 Ω, composite, Pin jack An NTSC or PAL signal can be outputted from camera |
| Đầu vào âm thanh | 3.5 mm stereo mini jack |
| Đầu ra âm thanh | 3.5 mm stereo mini jack (monaural output) Output impedance : Xấp xỉ. 600 Ω (unbalanced) Output level : 20 dBV |
| External I/O Terminals | ALARM IN 1 (Black & white input, Auto time adjustment input) (x1), ALARM IN 2 (ALARM OUT) (x1), ALARM IN 3 (AUX OUT) (x1) |
| Chứng nhận | UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1 |
| EMC | FCC (Part15 ClassA), ICES-003 ClassA, EN55032 ClassA, EN55035 |
| Nguồn điện & mức tiêu thụ | DC power supply : DC12 V 1.0 A, Xấp xỉ. 12.0 W PoE (IEEE802.3af compliant) Device : DC48 V 240 mA, Xấp xỉ. 11.5 W (Class 0 device) |
| Nhiệt độ hoạt động | -10 °C to +50 °C (14 °F to 122 °F) (Power On range: 0 °C to 50 °C{32°F to 122 °F}) |
| Chống va đập | IK10 (IEC 62262) |
| Độ ẩm hoạt động | 10 to 90 % (no condensation) |
| Kích thước | Φ129.5 mm x 102.5 mm (H) { Φ5-3/32 inches x 4-1/32 inches (H)} Dome radius 41.5 mm {1-5/8 inches} |
| Trọng lượng | 800 g {1.77 lbs.} |
