| Image Sensor | Approx.1/2.8 type CMOS image sensor |
| Scanning Area | 5.57 mm (H) × 3.13 mm (V)
{7/32 inches (H) × 1/8 inches (V)} |
| Minimum Illumination | Color :
0.02 lx (30IRE, F2.1, 1/30s, AGC:11)*
0.03 lx (50IRE, F2.1, 1/30s, AGC:11)
0.0019 lx (50IRE, F2.1, 16/30s, AGC:11)*
BW :
0 lx (50IRE, F2.1, 1/30s, AGC:11, IR LED: On)
0.02 lx (50IRE, F2.1, 1/30s, AGC:11)
0.0013 lx (50IRE, F2.1, 16/30s, AGC:11)*
*Converted value |
| White Balance | ATW1/ ATW2/ AWC |
| Maximum shutter | 60 fps/30 fps/15 fps mode: Max.1/10000s to Max.16/30s
50 fps/25 fps/12.5 fps mode: Max.1/10000s to Max.16/25s |
| Intelligent Auto | On / Off |
| Super Dynamic | On / Off,
The level can be set in the range of 0 to 31. *1 |
| Dynamic Range | 144 dB max.
(Super Dynamic: On, Level: 31) |
| Adaptive Black Stretch | The level can be set in the range of 0 to 255. |
| Back Light Compensation/ High Light Compensation | BLC/ HLC/ Off, The level can be set in the range of 0 to 31.
(only when Super Dynamic/ Intelligent Auto: Off) |
| Fog Compensation | On/ Off,
The level can be set in the range of 0 to 8.
(only when Intelligent Auto/ Auto contrast adjust: Off) |
| Maximum Gain (AGC) | The level can be set in the range of 0 to 11. |
| Color/BW (ICR) | Off/ On(IR Light Off)/ On(IR Light On)/ Auto1(IR Light Off)/ Auto2(IR Light On)/ Auto3(SCC) |
| IR LED Light | High/ Middle/ Low/ Off
Maximum irradiation distance : 21 m {Approx. 69 ft} (30IRE)* , 15 m {Approx. 49 ft} (50IRE)
* Converted value |
| Digital Noise Reduction | The level can be set in the range of 0 to 255. |
| Video Motion Detection (VMD) | On/ Off,
4 areas available |
| Scene Change Detection (SCD) | On/ Off,
1 area available |
| Audio Detection | On/ Off |
| AI Sound Classification | Selectable from Gunshot, Yell, Vehicle horn, Glass break |
| AI Analytics | AI Video Motion Detection, AI Privacy Guard, AI Face Detection, AI People Detection, AI Vehicle Detection, AI Non mask Detection (prior to V2.70), AI Occupancy Detection, AI Scene Change Detection |
| Privacy Zone | On/ Off,
up to 8 zones available |
| VIQS | On/ Off,
up to 8 zones available |
| Image Rotation | 0° (Off)/ 90°/ 180° (Upside-down)/ 270° |
| Camera Title (OSD) | On/ Off, Up to 40 characters, Up to 2 Lines
(alphanumeric characters, marks) |
