| Camera |
| Max Resolution | 4 MP |
| Sensor | 1/2.8" CMOS |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| WDR | 120 dB |
| S/N | > 56 dB |
| Min. Illumination | Color: 0.003 Lux (F1.5, AGC ON),
B/W: 0.002 Lux (F1.5, AGC ON),
0 Lux with Light |
| Case Type | PT |
| Lens |
| Focal Length | 4.5 to 148.5 mm |
| Digital Zoom | 8X |
| Optical Zoom | 33X |
| Iris | F1.5 to F4.0 |
| DORI |
| DORI Distance (Detect) | 105.8 m to 3172.5 m (346.9 ft. to 10408.5 ft) |
| DORI Distance (Observe) | 42.3 m to 1269.0m (138.8 ft. to 4163.4 ft) |
| DORI Distance (Recognize) | 21.2 m to 634.5 m (69.4 ft. to 2081.7 ft) |
| DORI Distance (Identify) | 10.6 m to 317.3 m (34.8 ft. to 1040.8 ft) |
| Video |
| Video Compression | H.265, H.264, MJPEG, Ultra 265 |
| Frame Rate | Main Stream Max: 4 MP (2688 × 1520), 60 fps
Main Stream Default: 4 MP (2560 × 1440), 25 fps
Sub Stream Max: 1080P (1920 × 1080), 60 fps
Third Stream Max: D1 (720 × 576), 60 fps
Fourth Stream Max: D1 (720 × 576), 60 fps
Fifth Stream Max: D1 (720 × 576), 60 fps |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| U-code | Support |
| Privacy Mask | 24 areas, up to 8 areas per scene |
| ROI | Up to 8 areas |
| Video Stream | Five streams |
| OSD | Up to 10 OSDs |
| Frame Rate Recommendation | 2688 × 1520@60 fps + 1080P@60 fps + D1@30 fps
2688 × 1520@60 fps + 720P@60 fps + D1@60 fps + D1@60 fps + D1@60 fps
2560 × 1440@30 fps + 1080P@60 fps + D1@60 fps
1080P@60 fps + 1080P@60 fps + D1@60fp + D1@60fp + D1@60fp |
| Events |
| General Function | Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, Alarm input, Alarm output, HTTP authentication |
| Audio |
| Audio Compression | G.711U, G.711A |
| Two-way Audio | Support |
| Suppression | Support |
| Sampling Rate | 8 kHz, 16 kHz |
| Storage |
| Edge Storage | MicroSD, up to 512 GB |
| Network Storage | NAS (NFS) |
| Network |
| Protocols | SSH, IGMP, RTP, RTMP, RTCP, IPv4, SSL/TLS, QoS, 802.1x, HTTPS, HTTP, UPnP, NTP, DDNS, DNS, RTSP, DHCP, UDP, TCP, ARP, ICMP, IPv6, SMTP, PPPoE, SNMP |
| Compatible Integration | SDK, API, ONVIF (Profile S, Profile G, Profile T, Profile M) |
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF, TLS 1.3 |
| Client | EZStation, UNV-Link, UNV-Link Pro |
| Web Browser | Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+ |
| PTZ |
| Preset Image Freeze | Support |
| Preset Patrol | 16 patrols, up to 64 presets for each patrol |
| Patrol Stay Time | 15 s to 1800 s |
| Home Position | Support |
| Number of Presets | 1024 |
| Pan Range | 360° (endless) |
| Pan Speed | 0.1°/s to 288°/s |
| Tilt Range | -15° to 90° (auto flip) |
| Tilt Speed | 0.1°/s to 288°/s |
| Image |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2, Area white balance |
| Digital Noise Reduction | 2D/3D DNR |
| BLC | Support |
| Flip | Normal, Flip vertical, Flip horizontal, 180° |
| HLC | Support |
| Defog | Digital defog |
| Low Illumination Characteristics | ColorHunter with Wise-ISP |
| Image Stabilization | EIS (Gyroscope) |
| Interface |
| Audio I/O | 1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p] |
| Alarm I/O | 2/1 |
| Network | 1 × RJ45 10 M/100 M Base-TX Ethernet |
| Serial Port | 1 × RS485 |
| Intelligent |
| Exception Detection | Object removed, Object Left Behind |
| Auto Tracking | UNV Large Model |
| Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
| People Counting | Support people flow counting and crowd density detection |
| Recognition | |
| Illuminator |
| IR On/Off Control | Auto/Manual |
| Illumination Distance (IR) | 250 m (820.2 ft) |
| Certification |
| Safety | UL (UL 62368-1)
CUL (CAN/CSA C22.2 No. 62368-1)
CE-LVD (EN IEC 62368-1) |
| EMC | CE-EMC (EN 55032; EN IEC 61000-3-2; EN 61000-3-3; EN 50130)
FCC SDoC (47 CFR Part 15; Subpart B) |
| Environment | CE-ROHS (2011/65/EU; (EU) 2015/863) WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) ; IK10 (IEC62262; Anti-Vandalism Except for the
Front Window) |
| General |
| Power Interface | Wires with cold-pressed terminal |
| Dimensions | Ø227 mm × 390 mm (Ø8.9" × 15.4") (Ø × H) |
| Weight | 5.21 kg (11.48 lb) |
| Storage Environment | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Surge Protection | 6 KV |
| Working Environment | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing) |
| Reset Button | Support |
| Power | DC 24 V±25%, AC 24 V±25%, PoE (IEEE 802.3at) |
| Power Consumption | Max. 20.9 W |
| Configurable |
| P/N | Support |
| Live View |
| 3D Privacy Mask | Support |
