Sensor | 1/2.8″, 2.0 megapixel, progressive scan, CMOS |
Lens | 4.5 ~ 148.5mm, AF automatic focusing and motorized zoom lens |
Digital Zoom | 16 |
Optical Zoom | 33 |
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
4.5 | 69.8 | 27.9 | 14 | 7 |
148.5 | 2304.3 | 921.7 | 460.9 | 230.4 |
Angle of View (H) | 62.67° ~ 2.82° |
Angle of View (V) | 38.4° ~ 1.3° |
Angle of View (O) | 77.1° ~ 3.3° |
Shutter | Auto/Manual, shutter time: 1 ~ 1/100000s |
Minimum Illumination | Colour: 0.001Lux (F1.6, AGC ON) 0Lux with IR |
Iris | Auto/Manual, F1.6 ~ F5.3 |
Day/Night | IR-cut filter with auto switch (ICR) |
Digital noise reduction | 2D/3D DNR |
S/N | >52dB |
VF laser | Up to 500m (1640ft) |
Defog | Digital Defog |
WDR | 120dB |
Video |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
H.264 code profile | Baseline profile, Main Profile, High Profile |
Frame Rate | Main Stream: 2MP (1920*1080), Max 60fps; Sub Stream: 2MP (1920*1080), Max 60fps; Third Stream: D1 (720*576), Max 60fps |
HLC | Supported |
BLC | Supported |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 24 areas |
ROI | Up to 8 areas |
Motion Detection | Up to 4 areas |
Smart |
General Function | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
Audio |
Audio Compression | G.711 |
Two-way Audio | Supported |
Suppression | Supported |
Sampling Rate | 8KHZ |
Storage |
Edge Storage | Micro SD, up to 256GB |
Network Storage | ANR |
Network |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, SSL, QoS |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
Pan & Tilt |
Pan Range | 360° |
Pan Speed | 0.1°/s ~ 240°/s |
Preset speed: 300°/s |
Tilt Range | -15° ~ 90° (auto reverse) |
Tilt Speed | 0.1° ~ 160°/s |
Preset speed: 240°/s |
Number of Presets | 1024 |
Patrol | Preset patrol, route patrol, recorded patrol |
Home Position | Supported |
Interface |
Audio I/O | Audio interface |
1 Input: impedance 35kΩ; amplitude 2V [p-p] |
1 Output: impedance 600Ω; amplitude 2V [p-p] |
Alarm I/O | 1/1 |
Network | 1 RJ45 10M/100M Base-TX adaptive Ethernet network interface |
General |
Power | AC 24V±25% (default power supply), DC 24V±25%, PoE (PSE Required) |
Power consumption: 8 ~ 47W |
Dimensions (Ø x H) | Ø227 x 359.4mm (Ø8.9″ x 14.2″) |
Weight | 5.6kg (12.3lb) |
Working Environment | -40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing) |
Ingress Protection | IP66 |
IR | Built-in VF laser IR |
Reset Button | Supported |
