Sensor | 1/2.7″, 5.0 megapixel, progressive scan, CMOS |
Lens | 2.8mm@F1.0 | 4.0mm@F1.0 |
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
2.8 | 63.0 | 25.2 | 12.6 | 6.3 |
Angle of view(H) | 102.0° | 80.2° |
Angle of View (V) | 53.4° | 43.0° |
Angle of View (O) | 121.0° | 94.7° |
Adjustment angle | Pan: 3° ~ 360° | Tilt: 0° ~ 80° | Rotate: 3° ~ 360° |
Shutter | Auto/Manual, 1 ~ 1/100000s |
Minimum Illumination | Colour: 0.001Lux (F1.0, AGC ON) |
S/N | >56dB |
Defog | Digital Defog |
WDR | 120dB |
LEDs Number | 2 |
LED Distance | Up to 30m (98ft) |
Video |
Video Compression | Ultra265, H.265, H.264, MJPEG |
H.264 code profile | Baseline profile, Main profile, High profile |
Frame Rate | Main Stream: 5MP (2880*1620), Max 30fps; 4MP (2560*1440), Max 30fps;3MP (2304*1296), Max 30fps; 2MP (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360, Max 30fps; 2CIF (704*288), Max 30fps; CIF (352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360, Max 30fps; 2CIF (704*288), Max 30fps; CIF (352*288), Max 30fps; |
Video Bit Rate | 128 Kbps~16 Mbps |
9:16 Corridor Mode | Supported |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 4 areas |
ROI | Up to 8 areas |
Image |
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Digital noise reduction | 2D/3D DNR |
Smart Illumination | Support |
Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
Dewarping | NA |
HLC | Support |
BLC | Support |
Audio |
Audio Compression | G.711 |
Suppression | Supported |
Sampling Rate | 8KHZ |
Storage |
Edge Storage | Micro SD, up to 256GB |
Network Storage | ANR, NAS(NFS) |
Network |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
Client | EZStation EZView EZLive |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
Interface |
Built-in Mic | Supported |
Network | 1 RJ45 10M/100M Base-TX Ethernet |
Certifications |
Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
General |
Power | DC 12V±25%, PoE (IEEE 802.3af) |
Power consumption: Max 7.5W |
Dimensions (Ø x H) | Φ110.5 x 94.1mm (Ø4.4” x 3.7”) |
Net Weight | 0.44kg (0.97lb) |
Material | metal |
Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
surge protection | 2KV |
Ingress Protection | IP67 |
| | | | | | | | |
