Sensor | 1/2.7″, 2.0 megapixel, progressive scan, CMOS |
Min. Illumination | Colour:0.003 lux (F1.2, AGC ON) 0 lux with IR |
Day/Night | IR-cut filter with auto switch (ICR) |
Shutter | Auto/Manual, 1 ~ 1/100000s |
WDR | 120dB |
S/N | >52dB |
Lens |
Lens type | 2.7~13.5mm@F1.2, AF automatic focusing and motorized zoom lens |
Iris | Auto aperture |
Angle of View (H) | 30.6°~106.9° |
Angle of View (V) | 17.7°~56.0° |
Angle of View (O) | 37.6°~139.0° |
DORI |
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
2.7 | 70.9(232.5ft) | 28.4(93.0ft) | 14.2(46.5ft) | 7.1(23.3ft) |
13.5 | 247.5(812.0ft) | 99.0(324.8ft) | 49.5(162.4ft) | 24.8(81.2ft) |
Illuminator |
IR Range | Up to 30m (98 ft) IR range |
Wavelength | 850nm |
IR On/Off Control | Auto/Manual |
Video |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
Frame Rate | Main Stream: 2MP (1920*1080),Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; Third Stream: D1 (720*576), Max 30fps |
Video Bit Rate | 128 Kbps~16 Mbps |
H.264 Type | Baseline Profile/Main Profile/High Profile |
H.265 Type | Main Profile |
U-code | Support |
ROI | Up to 8 areas |
Video stream | Triple streams |
OSD | Up to 8 OSDs |
Privacy Mask | 24 areas, up to 4 blacks in the same picture |
Image |
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Digital noise reduction | 2D/3D DNR |
Smart IR | Support |
Flip | Normal/Flip Vertical/Flip Horizontal/180° |
HLC | Support |
BLC | Support |
Defog | Digital Defog |
Events |
General Function | Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
Audio |
Audio Compression | G.711U, G.711A |
Audio Bitrate | 64 Kbps |
Two-way Audio | Support |
Suppression | Support |
Sampling Rate | 8KHZ |
Storage |
Edge Storage | Micro SD, up to 256 GB |
Network Storage | ANR,NAS(NFS) |
Network |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK |
User/Host | Up to 32 users. 2 user levels: administrator and common user |
Security | Password protection, strong password, HTTPS encryption, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
Client | EZStation EZLive Ezview |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
Pan & Tilt |
Pan Range | 350° |
Pan Speed | 0.1°/s ~ 60°/s |
Preset speed: 60°/s |
Tilt Range | 0° ~ 90° |
Tilt Speed | 0.1° ~ 50°/s |
Preset speed: 50°/s |
Number of Presets | 1024 |
Patrol | Preset patrol |
Preset Image Freeze | N/A |
Home Position | Support |
Interface |
Audio I/O | N/A |
Alarm I/O | 1/1 |
Serial Port | 1 RS485 |
Built-in Mic | Support |
Built-in Speaker | Support |
WIFI | Support(IEEE802.11b/g/n) |
Network | 1 * RJ45 10M/100M Base-TX Ethernet |
Video output | N/A |
Certification |
EMC | FCC Part 15 EN 55032:2015 EN 55024:2010 EN 61000-3-2:2014 EN 61000-3-3-2013 |
Safety | IEC 62368-1 EN 62368-1 UL 60950-1 |
Environment | CE-ROHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006) |
Protection | N/A |
General |
Power | DC12V(±25%), PoE(IEEE 802.3at) |
Power consumption: Max 15W |
Power Interface | Ø 5.5mm coaxial power plug |
Dimensions (Ø x H) | Φ129 x 143.6mm (Φ5.1’’ x 5.7’’) |
Weight | 0.76kg(1.67lb) |
Working Environment | -10℃~50℃(14°F ~ 122°F),Humidity: ≤95% RH (non-condensing) |
Storage Environment | -40℃~70℃(-40°F ~ 158°F),Humidity: ≤95% RH (non-condensing) |
Surge protection | 2KV |
Vandal Resistant | N/A |
Ingress Protection | N/A |
Reset Button | Support |
