| Sensor | 1/1.8″, 8.0 megapixel, progressive scan, CMOS |
| Lens | 5.7 ~ 216.6mm, AF automatic focusing and motorized zoom lens |
| Digital Zoom | 16 |
| Optical Zoom | 38 |
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
| 5.7 | 146.3(479.8ft) | 58.5(191.9ft) | 29.3(96.0ft) | 14.6(48.0ft) |
| 216.6 | 4545.0(14911.4ft) | 1818.0(5964.6ft) | 909.0(2982.3ft) | 454.5(1491.1ft) |
| Angle of View (H) | 61.2° ~ 2.3° |
| Angle of View (V) | 36.8° ~ 1.3° |
| Angle of View (O) | 75.3° ~ 2.7° |
| Shutter | Auto/Manual; shutter time: 1 ~ 1/100000s |
| Minimum Illumination | Colour: 0.003Lux (F1.5, AGC ON)
0Lux with IR |
| Iris | Auto/manual; F1.5 ~ F4.8 |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >55dB |
| IR Range | UP to 250m (820ft) |
| Defog | Optical Defog & Digital Defog |
| WDR | 120dB |
| Video |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream: 8MP (3840*2160)@30fps;
Sub Stream: 2MP (1920*1080)@30fps;
Third Stream: D1 (720*576)@30fps
Fourth Stream:D1(720×576)@30fps
Fifth Stream:D1(720×576)@30fps |
| HLC | Supported |
| BLC | Supported |
| EIS | Supported (gyroscope) |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 24 areas(Up to 8 blacks or 8 mosaics in the same picture) |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| Event |
| General Function | Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio |
| Audio Compression | G.711 |
| Two-way audio | Supported |
| Suppression | Supported |
| Sampling Rate | 8KHZ |
| Storage |
| Edge Storage | Micro SD, up to 256GB |
| Network Storage | ANR |
| Network |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
| Pan & Tilt |
| Pan Range | 360° (endless) |
| Pan Speed | 0.1°/s ~ 180°/s |
| Preset speed: 300°/s |
| Tilt Range | -15° ~ 90° (auto reverse) |
| Tilt Speed | 0.1° ~ 180°/s |
| Preset speed: 240°/s |
| Number of Presets | 1024 |
| Patrol | Preset patrol, route patrol, recorded patrol |
| Home Position | Supported |
| Interface |
| Audio I/O | Audio cable |
| Input: impedance 1kΩ; amplitude 2V [p-p] |
| Output: impedance 600Ω; amplitude 2V [p-p] |
| Alarm I/O | 2/1 |
| Serial Port | 1 RS485 |
| Network | 1 RJ45 10M / 100M Base-TX Ethernet |
| General |
| Power | AC 24V ±25%, DC 24V±25%, PoE++ (IEEE 802.3bt) (IEEE802.3bt switch required) |
| Power consumption: Max 70W |
| Dimensions (Ø x H) | Φ270 x 496.7mm (Φ10.6” x 19.6”) |
| Weight | 9.69kg (21.4lb) |
| Working Environment | -40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing) |
| Ingress Protection | IP66 |
| Reset Button | Supported |
