Sensor | 1/1.8″, 4.0 megapixel, progressive scan, CMOS |
Lens | 5.7 ~ 228mm, AF automatic focusing and motorized zoom lens |
Digital Zoom | 16 |
Optical Zoom | 40 |
DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
5.7 | 107.2(351.8ft) | 42.9(140.7ft) | 21.4(70.4ft) | 10.7(35.2ft) |
228 | 3330.6(10927.2ft) | 1332.2(4370.9ft) | 666.1(2185.4ft) | 333.1(1092.7ft) |
Angle of View (H) | 58.5° ~ 2.1° |
Angle of View (V) | 34.9° ~ 1.2° |
Angle of View (O) | 72.0° ~ 2.5° |
Shutter | Auto/Manual; shutter time: 1 ~ 1/100000s |
Minimum Illumination | Colour: 0.0005Lux (F1.3, AGC ON) 0Lux with IR |
Iris | Auto/Manual; F1.3 ~ F4.6 |
WDR | 120dB |
Day/Night | IR-cut filter with auto switch (ICR) |
Digital noise reduction | 2D/3D DNR |
S/N | >56dB |
VF Laser | 650m(2132ft) |
Wiper | Support manual wiper function |
IR On/Off Control | Auto/Manual |
Defog | Optical Defog |
Video |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
Frame Rate | Main Stream: 4MP (2688*1520), Max 60fps; Sub Stream: 2MP (1920*1080), Max 60fps; Third Stream: D1 (720*576), Max 60fps Fourth Stream: D1 (720*576), Max 60fps Fifth Stream: D1 (720*576), Max 60fps |
Video Bit Rate | 128 Kbps~16 Mbps |
ROI | Up to 8 areas |
Video stream | Five streams |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 24 blacks (Up to 8 blacks / 8 mosaics in the same picture) |
Image |
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Digital noise reduction | 2D/3D DNR |
Flip | Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
EIS | Supported (gyroscope) |
HLC | Support |
BLC | Support |
Event |
General Function | Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
Audio |
Audio Compression | G.711 |
Two-way audio | Supported |
Suppression | Supported |
Sampling Rate | 8KHZ |
Storage |
Edge Storage | Micro SD, up to 256GB |
Network Storage | ANR,NAS(NFS) |
Network |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
Client | EZStation Ezview EZLive |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
Pan & Tilt |
Pan Range | 360° (endless) |
Pan Speed | 0.1°/s ~ 180°/s |
Preset speed: 300°/s |
Tilt Range | -15° ~ 90° (auto reverse) |
Tilt Speed | 0.1° ~ 180° |
Preset speed: 240°/s |
Number of Presets | 1024 |
Patrol | Preset patrol, route patrol, recorded patrol |
Home Position | Supported |
Interface |
Audio I/O | Audio cable |
1 input: impedance 1kΩ; amplitude 2V [p-p] |
1 output: impedance 600Ω; amplitude 2V [p-p] |
Alarm I/O | 7/2 |
Serial Port | 1 RS485 |
Network | 1 RJ45 10M/100M Base-TX Ethernet |
General |
Power | AC 24V ±25%, DC 24V±25%, PoE++ (IEEE 802.3bt) |
Power consumption: Max 62W |
Dimensions (Ø x H) | Φ270 x 497mm (Φ10.6” x 19.6”) |
Weight | 9.69kg (21.4lb) |
Working Environment | -40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing) |
Ingress Protection | IP66 |
Reset Button | Supported |
